Linea Space BTicino

Neutral terminal 22 poles

BT-FMM22N | 8012199180298
Neutral terminal 22 poles (1x25 mm2 + 21x16 mm2) for switchboards Serie E215 and Linea Space
Technical Characteristics
Number of poles 22
Nominal current 76 A
Connection type Screwing
Mounting method DIN rail
Number of inputs 1
Number of outputs 21
Suitable for solid conductors Yes
Suitable for stranded conductors Yes
Suitable for fine strand conductors Yes
Suitable for fine strand conductors without cable end sleeve No
Suitable for extra fine-strand conductors No
Suitable for extra fine-strand conductors without cable end sleeve No
Conductor cross section, input (Min-Max) 6-25 mm²
Conductor cross section, output (Min-Max) 1.5-16 mm²
Contact safe Yes
Height 30 mm
Width 176 mm
Depth 16 mm
Operating / setting temperature (Min-Max) -5-40 °C
Storage temperature (Min-Max) -25-70 °C
Type of distribution blocks Neutral
Terminals capacity (Min-Max) 1.5-25 mm²
Label space/information surface No
