Mcb 2P for photovoltaic - In= 25A - Vn= 800Vdc
LG-414450
|
3245064144506
Technical Characteristics
Built-in depth
44 mm
Release characteristic
B
Number of poles (total)
2
Number of protected poles
2
Rated current
25 A
Rated voltage
1000 V
Rated insulation voltage Ui
1000 V
Rated impulse withstand voltage Uimp
8 kV
Voltage type
DC
Flush-mounted installation
Yes
Concurrently switching neutral conductor
No
Pollution degree
2
Additional equipment possible
Yes
Width in number of modular spacings
2
Degree of protection (IP)
IP20
Width
70.8 mm
Height
88 mm
Depth
76 mm
degree of impact strength (IK)
IK02
Storage temperature (Min-Max)
-40-70 °C
Electric supplying direction
By the top
Terminal marking indication
Yes
Colour
Grey
RAL-number
7035
Halogen free
Yes
Connection type
Screwed terminal
Connection type
Cable
Label space/information surface
Yes
Mounting method
DIN rail
Documentation
2 documents
Technical Sheet
F01320EN-02 | PDF (398 KB) | EN
Instruction Use
LE05084AD | PDF (2.5 MB)
1 documents
Brochure
3246500 | PDF (978 KB) | EN
