Removable and rechargeable lamp - 2 modules
BT-Y4380
|
8005543749432
Description
The removable and rechargeable torch with automatic ignition device of MatixGO automatically turns on in case of power failure - 2 hours autonomy
Product characteristics
- Push & pull extraction system (press and extract) complete with charging base - ON / OFF switch and SPOT button to increase brightness when necessary - Ni-MH interchangeable batteries without "memory" effect
- removable torch
- 2 modules
- Color Neutral
- Packaging 100% plastic free: delivered with dedicated and new packaging in 100% paper, water-based painted and use of ecological glues.
Recommendations / Restrictions
- Indoor use only
Products benefits
Installation
- Easy installation system
Usage
- Torch that turns automaticcallly on in case of power failure with a push & pull extracting system
Advantages
- The torch lights up in the event of a blackout, allowing it to be extracted and used to reach the switchboard and reactivate the current
- Replaceable battery (4380N)
- It is coordinated with the Light Now aesthetic
Technical Characteristics
Mounting method
Built-in
Function
Escape route lighting
Suitable for labelling type
Other
Type of indicator
Single-sided
With pictogram
No
Suitable for standby switching
No
Suitable for continuous circuit
Yes
With remote switch connection
No
Supplied remote control
No
Emergency function monitoring system
None
Emergency power supply system
Peripheral (individual battery)
Battery technology
NiMH
Lamp type
LED not exchangeable
With light source
Yes
Suitable for number of light sources
2
Lamp holder
None
Number of lighting heads
1
Housing material
Plastic
RAL-number housing
9003
Housing colour
Grey
Material cover
Plastic, opal
Voltage type
AC
Nominal voltage (Min-Max)
110-230 V
Type of control gear
Not required
Exchangeable control gear
No
Light distributor
Diffuser lens/optic/panel
Energy efficiency class of the light source according to EU regulation 2019/2015
A
Constant light output (CLO)
No
Degree of protection (IP)
IP30
Degree of protection (NEMA)
Other
degree of impact strength (IK)
IK04
Protection class according to IEC 61140
None
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1 (Min-Max)
-5-35 °C
Rated luminous flux according to IEC 62722-2- 1 (Min-Max)
0-0 lm
Colour temperature (Min-Max)
4000-5500 K
Recognition distance
5 m
Nominal operation time (Min-Max)
2-2 h
Width
45 mm
Height/depth
45 mm
Length
44.5 mm
Built-in width
45 mm
Built-in height/depth
45 mm
Built-in length
33 mm
Type of wiring
Ending
Conductor cross section
1.5 mm²
Connection type
Screw connection
Connectable conductor cross section (Min-Max)
1.5-2.5 mm²
Operating / setting temperature (Min-Max)
-5-35 °C
Storage temperature (Min-Max)
-10-70 °C
Frequency (Min-Max)
50-60 Hz
Mandatory neutral
No
Terminal marking indication
No
Halogen free
Yes
Cable nature for connection
Flexible or rigid
With complemantary luminous signal
No
Vertical fixing center distance (Min-Max)
3.5-3.7 mm
Horizontal fixing center distance (Min-Max)
3-3.2 mm
Cable support
Screw cable clamp
Cable tie suitable with
All conduit/cable types
Control mode
Not applicable
Contains Batteries and/or Accumulator
Yes
Addressable
No
Battery ou Accumulator (Pack1)
Accumulator (rechargeable)
Element Composition (Pack1)
Nickel metal hydride
Connected object
No
Programming way
Not applicable
With voice command
No
Programmable
No
Interoperable connection Protocol
No
Connectable by Internet box
No
Product use function
Emergency Lighting
