Plastic wall-mounting distribution board SDX-P 515x1000x145mm with panels 144 modules
BT-94561P
|
8012199785820
Technical Characteristics
Mounting method
Surface mounted
number of rows
5
Width in number of modular spacings
144
Type of covering
Optional
Cover model
Closed
Transparent cover/door
Yes
With lock
Yes
Housing material
Plastic
Built-in depth
25 mm
Inner depth
120 mm
DIN-rail
Yes
With mounting plate
No
Extension possible
No
Colour
Grey
EMC-version
No
RAL-number
7035
Degree of protection (IP)
IP43
Height
1050 mm
Width
600 mm
Depth
145 mm
Documentation
1 documents
Instruction Use
F0328B | PDF (1.4 MB)
