Smart Modulating Thermostat
NA-OTH-PRO
|
3700730503723
Description
Netatmo Smart Modulating Thermostat - Comfort and energy savings, every day - compatible with most OpenTherm modulating boilers
Product characteristics
- Remote control
- Smart OpenTherm Modulation
- System alert in case of problem
- Hot water control with separate schedule
- Wireless Installation
Recommendations / Restrictions
- Compatible with Open Therm modulating boilers only. Wireless installation Only
Products benefits
Installation
- Easy to set up : it takes less than 1h to install
Usage
- Wireless : place the Thermostat anywhere you want in your home
Advantages
- Smart heating schedule and remote control
- Auto-Adapt feature and OpenTherm modulation: always the right temperature, whatever the weather
- Domestic hot water control on OpenTherm system boilers
Technical Characteristics
Regulation type on/off
Yes
Regulation type modulating
Yes
Communications protocol
OpenTherm
Type of power supply
Battery
Connection
Wireless
Measuring range (Min-Max)
0-50 °C
External sensor
No
With thermal feedback
Yes
Control characteristic
PID
Adaptive (self-learning)
Yes
Suitable for heating
Yes
Number of heater outputs
1
Suitable for cooling
No
Number of cooler outputs
0
Ventilation
No
Number of ventilation outputs
0
Differential value (Min-Max)
0-0 K
Sensor/feeler type
Resistance sensor
Temperature readable
Yes
With display
Yes
Type of clock
Day clock
Clock model
Digital
Optimisation
Yes
With tap water circuit
Yes
Operation
Button
Suitable for floor heating control
No
Suitable for district heating control
No
Remote operation possible
Yes
IFTTT support available
No
With presence perception
No
Weather-dependent control system
Yes
Number of switching programmes
3
Max. contact voltage
250 V
Max. contact load
4 A
Degree of protection (IP)
IPX0
Colour
White
Width
83 mm
Depth
22 mm
Height
83 mm
Class of the temperature control
VI
degree of impact strength (IK)
Not applicable
Operating / setting temperature (Min-Max)
5-30 °C
Storage temperature (Min-Max)
0-50 °C
Voltage type
AC/DC
Mounting method
Surface mounted
Contains Batteries and/or Accumulator
Yes
IEC code (Pack1)
LR03
Battery ou Accumulator (Pack1)
Battery (not rechargeable)
Element Composition (Pack1)
Alkaline
Number of Pack 1
3
Number of Single Element (Pack1)
1
Single Element weight (Pack1)
33 g
Pack1 Location
Included in packaging
Regulation Type (Pack1)
P : Portable (Standard format)
Connected object
Yes
Operating method
Wifi network 2.4G, RF
Application store for download
App Store, Google Play Store
Programming way
Smartphone apps
With voice command
Yes
Programmable
Yes
Interoperable connection Protocol
Yes
Connectable by Internet box
Yes
Compatible voice assistants
Google Assistant, Apple Siri, Amazon Alexa
Application name
Home + Control
Product use function
Thermal comfort management
Software Update Duration (years)
3
Documentation
1 documents
Instruction Use
OTH-QSG-V3-WEB | PDF (1.8 MB) | DE · EN · ES · FR · IT · NL
