Disconnector MW160 - 3P - 125A
BT-T7133WF/125
|
8012199672533
Technical Characteristics
Version as main switch
Yes
Version as maintenance-/service switch
Yes
Version as safety switch
No
Version as emergency stop installation
No
Max. rated operation voltage Ue AC
690 V
Rated permanent current Iu
125 A
Rated operation power at AC-23, 400 V
70 kW
Conditioned rated short-circuit current Iq
12 kA
Number of poles
3
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
0
Motor drive optional
No
Motor drive integrated
No
Voltage release optional
No
Device construction
Built-in device fixed built-in technique
Suitable for floor mounting
No
Suitable for front mounting 4-hole
Yes
Suitable for front mounting centre
Yes
Suitable for distribution board installation
Yes
Suitable for intermediate mounting
No
Type of control element
Wing knob
Interlockable
Yes
Type of electrical connection of main circuit
Screw connection
Degree of protection (IP), front side
IP2X
Documentation
1 documents
Instruction Use
80196B | PDF (309 KB)
