Classia BTicino

One-way switch 1P 16 AX - 250 Vac - lightable - boiler symbol

BT-RG4001LS | 8005543633496
1-way switch 1P 16 AX - 250 Vac - lightable with LED lamp 230 V included - 1 module - boiler symbol - Black
Description

Switch 1P 16 AX - 250 Va.c. - lightable with led lamp 230 V included - boiler symbol, 1 module, color black satin

Product characteristics
  • Switch 1P 16 AX - 250 Va.c. - lightable with led lamp 230 V included - boiler symbol
  • 1 module
  • color black
  • screw terminals
Products benefits
Installation
  • Easy to insall and remove
Usage
  • The led inside gives a clear, insense bright beam
Advantages
  • Higt technical performance
  • modern shape, slightly curved cover
Technical Characteristics
Wiring system Switch 1-pole
Method of operation Rocker/button
Assembly arrangement Modular device for domestic switching devices
Number of modules (module system) 1
Push button switch Yes
Mounting method Flush-mounted
Type of fastening Engage (snap)
With mounting plate No
Material Plastic
Material quality Thermoplastic
Halogen free Yes
Antimicrobial treatment No
Surface protection Untreated
Surface finishing Matt
Colour Black
RAL-number (similar) 9011
Colour of switch operator Black
Label space/information surface No
Lighting Yes
Function lighting Orientation
Type of lighting LED exchangeable
Suitable for degree of protection (IP) IP20
Nominal voltage 250 V
Rated current 16 A
Switching current for fluorescent lamps 16 AX
Monitoring contact No
Connection type Screwed terminal
Heating switch No
Washing machine switch No
Device width 22.2 mm
Device height 45.1 mm
Device depth 42.7 mm
Built-in depth 32.9 mm
Min. depth of built-in installation box 30 mm
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
IFTTT support available No
Operating / setting temperature (Min-Max) -5-50 °C
Storage temperature (Min-Max) -10-70 °C
Voltage type AC
Frequency (Min-Max) 50-60 Hz
Mandatory neutral No
Terminal marking indication No
Cable nature for connection Flexible or rigid
Cable section (Min-Max) 1.5-2.5 mm²
Documentation
1 documents
Technical Sheet
IDP000233_02-EN | PDF (632 KB) | EN
1 documents
Catalog Commercial Page
3210144 | PDF (9.4 MB) | EN
