Undervoltage release Vn= 24Vdc - for M4 630 and M5 1600
BT-M7T024C
|
8005543529539
Technical Characteristics
Rated control supply voltage DC (Min-Max)
20.4-26.4 V
Voltage type for actuating
DC
Type of electric connection
Screw connection
Delayed
No
Suitable for power circuit breaker
Yes
Suitable for off-load switch
Yes
Suitable for motor safety switch
Yes
Width
98 mm
Height
51 mm
Depth
37 mm
Degree of protection (IP)
IP30
Operating / setting temperature (Min-Max)
-5-70 °C
Storage temperature (Min-Max)
-40-85 °C
Halogen free
Yes
Prewired
No
Terminals capacity (Min-Max)
0.35-2.5 mm²
Documentation
1 documents
Instruction Use
LE07033AB | PDF (912 KB)
1 documents
Catalog Commercial Page
3244051 | PDF (28.2 MB) | EN
