4 modules Living Now Plate
BT-KA4803KC
|
8005543783078
Description
The Living Now coverplate is the accessory that, together with the covers, is mounted on the functional part for the aesthetic completion of the switch. This 3-modules coverplate is of CHAMPAGNE finish on a Zamak base.
Product characteristics
- Extreme purity of the design and precision of geometries Living Now has a unique shape, compact, distinctive.
- Innovative design: perfect flatness of the switch thanks to a self-centering system of the covers that allows the controllers to always remain aligned to the plate, even after multiple drives.
- Floating Frame: a flexible frame, placed on the back of the coverplate,free to move on the four corners, ensuring an optimal installation. Thanks to the floating frame, Living Now seems fluctuating on the wall.
- 3 modules, satin Zama, CHAMPAGNE finish
- Delivered with dedicated packaging to maintain the aesthetic characteristics unaltered
Recommendations / Restrictions
- For internal use only.
Products benefits
Installation
- The Living Now coverplate is equipped with a flexible frame, placed on the back of the plate, free to move on the four corners, ensuring an optimal installation.
Usage
- Innovative Design: unique and compact shape that, once completed with the covers, gives the switch an absolute flatness. The coverplate togheter with the commands in the same color is the maximum expression of monolithic elegance and valorization.
Advantages
- These metal proposals go precisely to emphasize the monolithicity and value of the coverplate and controls in the space.
- The zamak coverplate embraces a premium approach, enriching and enhancing the object within the space.
- Floating frame: a flexible frame, placed on the back of the plate, free to move on the four corners, which guarantees an optimal installation by masking the imperfections of the wall or in the case of plasterboard boxes.
Technical Characteristics
Number of units
1
Mounting direction
Horizontal
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
With mounting grid
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for built-in installation
No
Label space/information surface
No
Material
Metal
Material quality
Other
Halogen free
Yes
Antimicrobial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Gold
RAL-number (similar)
1019
Transparent
No
With hinged lid
No
Degree of protection (IP)
Other
degree of impact strength (IK)
IK04
Type of fastening
Engage (snap)
Width
125 mm
Height
86 mm
Depth
30 mm
Built-in width
125 mm
Built-in height
86 mm
Operating / setting temperature (Min-Max)
-5-35 °C
Storage temperature (Min-Max)
-10-70 °C
Latin wood species
Not applicable
Certification of wood (list)
Not applicable
Wood Climate area
Not applicable
