  • BTDIN60 - Rcbo 2P - type AC - In= 63A - Icn= 4.5kA - Vn= 400Vac - Idn= 30mA
Btdin BTicino

BTDIN60 - Rcbo 2P - type AC - In= 63A - Icn= 4.5kA - Vn= 400Vac - Idn= 30mA

BT-GN823AC63 | 8005543479292
BTDIN60 - thermal-magnetic with earth leakage protection 2P - type AC - In= 63A - Icn= 4.5kA - Vn= 400 Vac - Idn= 30mA - 4 modules
Technical Characteristics
Number of poles (total) 2
Number of protected poles 2
Rated voltage 230 V
Rated current 63 A
Rated fault current 0.03 A
Leakage current type AC
Current limiting class 3
Rated short-circuit breaking capacity according to EN 61009 6 kA
Rated short-circuit breaking capacity according to IEC 60947-2 10 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1 6 kA
Frequency 50 Hz
Release characteristic C
Concurrently switching neutral conductor Yes
With interlocking device Yes
Pollution degree 2
Width in number of modular spacings 4
Built-in depth 44 mm
Degree of protection (IP) IP20
Documentation
1 documents
Technical Sheet
IDP000136EN-01 | PDF (1.5 MB) | EN
1 documents
PEP-EPD
LGRP-2015-079-V1-EN | PDF (954 KB) | EN
