Disconnector - In=16A - 3P - 2 modules
BT-F73N16
|
8005543487976
Technical Characteristics
Version as main switch
Yes
Version as maintenance-/service switch
No
Version as safety switch
Yes
Version as emergency stop installation
No
Version as reversing switch
No
Number of switches
3
Max. rated operation voltage Ue AC
400 V
Rated permanent current Iu
16 A
Rated short-time withstand current lcw
750 kA
Number of poles
3
Motor drive optional
No
Motor drive integrated
No
Device construction
Built-in device fixed built-in technique
Suitable for floor mounting
No
Suitable for front mounting 4-hole
No
Suitable for front mounting centre
No
Suitable for distribution board installation
Yes
Suitable for intermediate mounting
No
Colour control element
Grey
Type of control element
Wing knob
Interlockable
Yes
Type of electrical connection of main circuit
Screw connection
Degree of protection (IP), front side
IP20
Width
35.6 mm
Height
94.8 mm
Depth
76.4 mm
degree of impact strength (IK)
IK04
Operating / setting temperature (Min-Max)
-25-70 °C
Storage temperature (Min-Max)
-40-70 °C
Voltage type
AC/DC
Electric supplying direction
By the top or bottom
Colour
Grey
RAL-number
7035
Halogen free
Yes
Terminals capacity (Min-Max)
1.5-16 mm²
Connection type
Busbar and cable
Label space/information surface
Yes
