  • Flush-mounting box for plasterboards 3x18 modules for LINEA SPACE and E215 series
Linea Space BTicino

Flush-mounting box for plasterboards 3x18 modules for LINEA SPACE and E215 series

BT-F315SC54 | 8005543540732
Flush-mounting box (green) for plasterboards 3x18 modules for LINEA SPACE and E215 series switchboards
Technical Characteristics
Mounting method Flush-mounted
number of rows 3
Width in number of modular spacings 18
Type of covering Optional
Signal passing door Yes
With lock No
Type of closure Other
Housing material Plastic
Built-in depth 91 mm
Built-in height 602 mm
Built-in width 432 mm
Inner depth 84 mm
Earthing terminal block No
Neutral terminal block No
DIN-rail Yes
With mounting plate No
Extension possible Yes
Colour Other
RAL-number 6011
Degree of protection (IP) IP40
Height 606 mm
Width 436 mm
Depth 91 mm
Enclosure capacity (Nb of modules) 54
degree of impact strength (IK) Not applicable
Operating / setting temperature (Min-Max) -10-60 °C
Storage temperature (Min-Max) -20-70 °C
Fitted with rainproof plate protection No
Documentation
2 documents
Technical Sheet
IDP000065EN-02 | PDF (1.4 MB) | EN
Instruction Use
LE07390AA | PDF (433 KB)
