  6. BT-F305PT54
  • Wall mounted switchboard with box and transparent door, 54 modules
Linea wall BTicino

Wall mounted switchboard with box and transparent door, 54 modules

BT-F305PT54 | 8005543545843
Wall mounted switchboard with box and transparent door, 54 x DIN35 modules (600x450x150mm). Compliance with regulations IEC 60670-24 , CEI 23-48 , CEI 23-49, CEI 61439-3. IP40 and IK07 (6 joule) protection index. Material in thermoplastic resin. Insulating class II. RAL 9003 white wall mounted box. Operating temperature: -10 to 60 °C. Resistance to abnormal heat and fire (EN 60695-2-11): 650 °C. DIN35 rail type: Galvanized steel. Preset cut-outs for pipes (diameter) 16-32mm. Reversible door opening. Wall mounted box supplied
Technical Characteristics
Mounting method Surface mounted
number of rows 3
Width in number of modular spacings 18
Type of covering Door
Cover model Closed
Type of door Single
Transparent cover/door Yes
Signal passing door Yes
With lock No
Type of closure Other
Housing material Plastic
Built-in depth 124 mm
Built-in height 596 mm
Built-in width 446 mm
Inner depth 0 mm
Earthing terminal block No
Neutral terminal block No
DIN-rail Yes
With mounting plate No
Extension possible Yes
Colour White
EMC-version No
RAL-number 9003
Degree of protection (IP) IP40
Height 600 mm
Width 450 mm
Depth 128 mm
Enclosure capacity (Nb of modules) 54
degree of impact strength (IK) IK05
Operating / setting temperature (Min-Max) -5-40 °C
Storage temperature (Min-Max) -15-40 °C
Fitted with rainproof plate protection No
