Wall mounting Cover IP40 in resin for 6 modules - 128x160x74 mm
BT-F115/6D
|
8012199228167
Technical Characteristics
Mounting method
Surface mounted
number of rows
1
Width in number of modular spacings
6
Type of covering
Cover
Cover model
With notch
Transparent cover/door
No
Signal passing door
Yes
With lock
No
Type of closure
Other
Housing material
Plastic
Built-in depth
70 mm
Built-in height
156 mm
Built-in width
124 mm
Inner depth
0 mm
Earthing terminal block
No
Neutral terminal block
No
DIN-rail
Yes
With mounting plate
No
Extension possible
No
Colour
White
EMC-version
No
RAL-number
9010
Degree of protection (IP)
IP30
Height
160 mm
Width
128 mm
Depth
74 mm
Enclosure capacity (Nb of modules)
6
degree of impact strength (IK)
IK05
Operating / setting temperature (Min-Max)
-10-60 °C
Storage temperature (Min-Max)
-25-70 °C
Halogen free
No
Fitted with rainproof plate protection
No
