IP system BTicino

Plug-in power supply for IP server 375001

Name: Plug-in power supply for IP server 375001
Brand: BTicino
SKU: BT-SP111
Availability: InStock

BT-SP111 | 8005543732014

Plug-in power supply for IP server 375001. Input 100-240 Vac @ 50-60 Hz. Output 19 Vdc. Length of connection cable with IP server = 1200 mm

Compare

Technical Characteristics

Application Other

Input voltage 240 V

Frequency (Min-Max) 56-60 Hz

Type of current DC

Output voltage 19 V

Height 25 mm

Width 116 mm

Depth 52 mm

Operating / setting temperature (Min-Max) 0-60 °C

Storage temperature (Min-Max) -25-70 °C

Colour Black

Documentation

Catalog Wiring Diagram

3250957 | PDF (3.8 MB) | EN

Catalog Commercial Page

3248452 | PDF (12.7 MB) | EN
