Axolute BTicino

Removable and rechargeable torch with automatic ignition device

BT-H4380N | 8005543540084
Removable and rechargeable torch with automatic ignition device. It turns on automatically in case of power failure - push & pull the extraction system (press and pull) complete with recharging base - white Light LEDs with high luminous efficiency - ON / OFF switch and SPOT button to increase the brightness when needed - interchangeable batteries Ni-MH battery without memory effect - Autonomy of 2 hours - low consumption in stand-by 0.4W - Power 230 VAC - 2 modules - supplied in box with base and Front cover plate in opaline finish, neutral
Technical Characteristics
Mounting method Built-in
Suitable for labelling type Sticker
Suitable for continuous circuit Yes
With remote switch connection No
Emergency function monitoring system None
Emergency power supply system Peripheral (individual battery)
Battery technology NiMH
Lamp type LED not exchangeable
With light source Yes
Lamp holder Other
Housing material Plastic
Housing colour Other
Material cover Plastic, opal
Voltage type AC
Nominal voltage (Min-Max) 110-240 V
Nominal current (Min-Max) 450-450 mA
Degree of protection (IP) Other
Rated luminous flux according to IEC 62722-2- 1 (Min-Max) 0-0 lm
Nominal operation time (Min-Max) 2-2 h
Width 45 mm
Height/depth 43 mm
Length 45 mm
Built-in width 45 mm
Built-in height/depth 39 mm
Built-in length 45 mm
Contains Batteries Yes
Number of batteries (Type 1) 2
Battery ou Accumulator (Type 1) Accumulator (rechargeable)
Battery Composition (Type 1) Rechargeable - Nickel-Metalhydride
Battery weight (g) for Type 1 9
Total weight of the batteries (Type 1) 18
Battery Location (Type 1) Product includes a battery
Regulation Type (Type 1) I : Industrial (not Portable)
Connected object No
Battery weight (g) for Type 1 3 g
Number of Single Element (Pack1) 3
Documentation
1 documents
Instruction Use
LE08308AA | PDF (500 KB)
1 documents
Catalog Commercial Page
3211578 | PDF (16.1 MB) | EN
