Name: Webserver
Brand: BTicino
SKU: IM-SXWS10
Availability: InStock

Description

The WebServer manages up to 10 measuring devices and allows the display of measurements via web pages

Product characteristics

Power supply 9 to 28Vdc
Protection against overvoltages and polarity inversions by self-resetting 1.1A fuse
Protected against usual bodies up to 12.5mm wide: IP20 according to IEC / EN 60529.

Products benefits

Installation

Through a clear and intuitive graphic layout, among other functions, it is possible to remotely view the states, the electrical quantities, remotely control the activation modules and manage the alarms.

Technical Characteristics

Supply voltage DC (Min-Max) 9-28 V

Voltage type (supply voltage) DC

Supporting protocol for TCP/IP Yes

Supporting protocol for PROFIBUS No

Supporting protocol for CAN No

Supporting protocol for INTERBUS No

Supporting protocol for ASI No

Supporting protocol for KNX No

Supporting protocol for Modbus Yes

Supporting protocol for Data-Highway No

Supporting protocol for DeviceNet No

Supporting protocol for SUCONET No

Supporting protocol for LON No

Supporting protocol for SERCOS No

Supporting protocol for PROFINET IO No

Supporting protocol for PROFINET CBA No

Supporting protocol for Foundation Fieldbus No

Supporting protocol for EtherNet/IP Yes

Supporting protocol for AS-Interface Safety at Work No

Supporting protocol for DeviceNet Safety No

Supporting protocol for INTERBUS-Safety No

Supporting protocol for PROFIsafe No

Supporting protocol for SafetyBUS p No

Supporting protocol for other bus systems No

Radio standard Bluetooth No

Radio standard WLAN 802.11 No

Radio standard GPRS No

Radio standard GSM No

Mobile communications standard 3G (UMTS) No

IO link master No

System accessory Yes

Degree of protection (IP) IP20

With potential separation Yes

Fieldbus connection over separate bus coupler possible Yes

Suitable for rail mounting Yes

Wall mounting/direct mounting Yes

Front built-in possible No

Rack-assembly possible No

Suitable for safety functions Yes

SIL according to IEC 61508 None

Performance level according to EN ISO 13849-1 None

Appendant operation agent (Ex ia) No

Appendant operation agent (Ex ib) No

Explosion safety category for gas None

Explosion safety category for dust None

Width 71.3 mm

Height 90.5 mm

Depth 62 mm
