  6. BT-FL4649
  • Advanced Black touch badge holder, Premium line in BUS-SCS with RID reader for hotel room power supply.
Smart Hotel BTicino

Advanced Black touch badge holder, Premium line in BUS-SCS with RID reader for hotel room power supply.

BT-FL4649 | 8005543620540
Advanced key card switch, in plastic material (Black color).It allows the activation of the hotel room functions with RFID technology recognition, and to controlthe outside the door DO NOT DISTURB (DND) and “MAKE UP THE ROOM (MUR) notifications.Moreover, based on the information stored on the key card (CUSTOMER or STAFF), it allows to recall different scenarios.Slot for key card with built-in Lighting.Connection to SCS-BUS, dimension: 3 modules.
Description

the key-card reader can differentiate guest or staff badges and launch different actions. It can also activate different room services like DND or MUR.

Product characteristics
  • Full touch plate surface
  • surface mounted installation or fully flush-mounted
  • Action on the product with visual feedback for the user
Recommendations / Restrictions
  • to be used within Legrand Guest room management system
Products benefits
Installation
  • Installation in standard back boxes with its own support frame. No dedicated box required
Usage
  • Improved user experience thanks to intuitive icons and feedback upon actions
Advantages
  • Action feedback for the user
  • Full flush mounted installation option
  • Icons backlit only when needed by guest
Technical Characteristics
Bus system KNX No
Bus system KNX-RF (Radio Frequency) No
Bus system radio frequency No
Bus system LON No
Bus system Powernet No
Other bus systems Other
Radio frequency bidirectional No
Mounting method Flush-mounted
With anti-theft/dismantling protection No
With bus connection Yes
Number of actuation points 0
Number of buttons 2
With LED indication Yes
With label area No
With display Yes
Material Plastic
Material quality Thermoplastic
Surface protection Untreated
Surface finishing Glossy
Colour Black
RAL-number (similar) 9017
Transparent No
With room temperature controller No
With IR sensor No
Degree of protection (IP) IP20
Min. depth of built-in installation box 55 mm
Width 129 mm
Height 93 mm
Depth 48 mm
Built-in depth 30 mm
degree of impact strength (IK) IK02
Operating / setting temperature (Min-Max) 0-40 °C
Storage temperature (Min-Max) -20-70 °C
Frequency (Min-Max) 0-0 Hz
Standby consumption 12 mA
Terminal marking indication Yes
Halogen free Yes
Antimicrobial treatment No
Terminals capacity (Min-Max) 0-0 mm²
Cable nature for connection Flexible or rigid
Label space/information surface No
Addressable Yes
Connected object No
Operating method SCS
Programmable Yes
Documentation
1 documents
BIM Data
BIM_HOTEL_UX_TOUCH_KEYCARD | RFA (604 KB) | EN
