RJ11 connector type K10
BT-RW4258RJ11
|
8005543634509
Description
Telephone socket RJ11 connector type K10. It allows the connection of a device to the telephone network. 1 module, color white
Product characteristics
- Telephone socket with screw connection that allows a pass through installation
- 1 module
- color white
- RJ11 connector type K10
- screw terminal
Recommendations / Restrictions
- Indoor use only.
Products benefits
Installation
- Easy to insall and remove
Technical Characteristics
Surface mounting
No
Duct installation
No
Floor box/subfloor mounted
No
Type of fastening
Engage (snap)
Assembly arrangement
Other
Type of connector
Other
With buses/couplings
Yes
Suitable for number of connectors
1
Category
Other
Colour
White
RAL-number
9003
Connection type
Other
Shielded buses
No
Shielded housing
No
Separate earthing connection
No
With label space
Yes
Separate strain relief
No
Mounting method shielding connection
Other
Outlet direction
Straight
With dust cover
No
Degree of protection (IP)
IP20
Mechanical coding
No
Colour coding
No
Device width
22.3 mm
Device height
45.1 mm
Device depth
42.7 mm
Built-in depth
42.7 mm
degree of impact strength (IK)
Not applicable
Operating / setting temperature (Min-Max)
-5-50 °C
Storage temperature (Min-Max)
-10-70 °C
Terminal marking indication
No
Halogen free
Yes
Antimicrobial treatment
No
Mounting method
Flush-mounted
Entry membrane gland type
Flexible to cut
Vertical fixing center distance (Min-Max)
3.5-3.7 mm
Horizontal fixing center distance (Min-Max)
3-3.2 mm
Cable support
Screw cable clamp
