Removable LED lamp
BT-R4380
|
8005543636213
Description
Rechargabel torch that turns automaticcallly on in case of power failure. Push & Pull extracting system. 2 modules.
Product characteristics
- It automatically turns on in the case of power failure. Push & Pull extracting system - high efficiency white LED - ON / OFF switch and SPOT button to increase light intensity if needed - interchangeable Ni-MH batteries with 2h duration - low consuption in stand-by 0,4W . Recharging base.
- 2 modules
- screw terminals
- 127 / 230V power supply
Products benefits
Installation
- Easy installation system
Usage
- Torch that turns automaticcallly on in case of power failure with a push & pull extracting system
Technical Characteristics
Mounting method
Built-in
Function
Escape route lighting/signage
With pictogram
No
Suitable for continuous circuit
Yes
With remote switch connection
No
Supplied remote control
No
Emergency function monitoring system
None
Emergency power supply system
Central (central battery)
Battery technology
NiMH
Lamp type
LED not exchangeable
Housing material
Plastic
RAL-number housing
9003
Housing colour
White
Material cover
Plastic, opal
Voltage type
AC
Nominal voltage (Min-Max)
127-230 V
Degree of protection (IP)
IP40
degree of impact strength (IK)
IK04
Protection class according to IEC 61140
None
Rated luminous flux according to IEC 62722-2- 1 (Min-Max)
0-0 lm
Nominal operation time (Min-Max)
2-2 h
Width
45 mm
Height/depth
44.6 mm
Length
45.1 mm
Built-in width
45 mm
Built-in height/depth
31 mm
Built-in length
45.1 mm
Operating / setting temperature (Min-Max)
-5-35 °C
Storage temperature (Min-Max)
-10-70 °C
Frequency (Min-Max)
50-60 Hz
Mandatory neutral
No
Terminal marking indication
No
Halogen free
Yes
Cable nature for connection
Flexible or rigid
With complemantary luminous signal
No
Vertical fixing center distance (Min-Max)
3.5-3.7 mm
Horizontal fixing center distance (Min-Max)
3-3.2 mm
Cable support
Screw cable clamp
Cable tie suitable with
Flexible conduit
Control mode
Not applicable
Contains Batteries and/or Accumulator
Yes
Addressable
No
Battery ou Accumulator (Pack1)
Accumulator (rechargeable)
Element Composition (Pack1)
Nickel metal hydride
Number of Pack 1
1
Number of Single Element (Pack1)
1
Single Element weight (Pack1)
10 g
Pack1 Location
Product includes a battery
Regulation Type (Pack1)
P : Portable (Standard format)
Connected object
No
Documentation
2 documents
Technical Sheet
IDP000249_01-EN | PDF (485 KB) | EN
Instruction Use
LE10812AB | PDF (475 KB)
1 documents
Catalog Commercial Page
3210144 | PDF (9.4 MB) | EN
