MEGATIKER BTicino

Undervoltage release for M160-M1600ES Vn= 48Vdc

Name: Undervoltage release for M160-M1600ES Vn= 48Vdc
Brand: BTicino
SKU: BT-M4M/048C
Availability: InStock

BT-M4M/048C | 8012199097459

Compare

Technical Characteristics

Rated control supply voltage DC (Min-Max) 40.8-52.8 V

Voltage type for actuating DC

Type of electric connection Other

Delayed No

Suitable for power circuit breaker Yes

Suitable for off-load switch Yes

Suitable for motor safety switch Yes

Width 104 mm

Height 41 mm

Depth 67 mm

Degree of protection (IP) IP30

Operating / setting temperature (Min-Max) -5-70 °C

Storage temperature (Min-Max) -40-85 °C

Halogen free Yes

Prewired Yes

Documentation

Instruction Use

80037C | PDF (611 KB)

Catalog Commercial Page

3244051 | PDF (28.2 MB) | EN
