STOP symbol silk-screen printing for shutters - 1 module - Black
BT-KG06MH
|
8005543618998
Description
cover with serigraphy stop LIVING NOW black
Product characteristics
- specific symbol to indicate performed function
- 1 module
Products benefits
Usage
- an intuitive symbol allows to easily identify related function
Advantages
- new design that guaratees completly flat commands, with perfect wall alignement and new ergonomy for a full touch interaction
- the maximun quality in terms of materials and installation
Technical Characteristics
Model
One-part button
Imprint/indication
Other
Scannable symbol/barrier free
No
Utilization
Venetian blind
Suitable for touch sensor connector for bus system
No
Type of fastening
Engage (snap)
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Antimicrobial treatment
No
Colour
Black
RAL-number (similar)
7015
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP20
degree of impact strength (IK)
IK04
Width
22 mm
Height
86 mm
Depth
7 mm
Operating / setting temperature (Min-Max)
-5-35 °C
Storage temperature (Min-Max)
-10-70 °C
