Fan controller 110-220 VA 15-160 Va.c. 50-60Hz
BT-KC4018
Description
The Living Now Fan control permits you to reduce or increase the intensity of a ventilation blade - bi-voltage - 1 module
Product characteristics
- Can be used in circuits working both 110 V and 230V
- The device is already supplied with its corresponding white 1-module cover
- Screw and plate terminals
- Easy installation and removal of the mechanism on the support frame thanks to the new generation of plastic hooking system
- Delivered with dedicated packaging to maintain the aesthetic characteristics unaltered
Recommendations / Restrictions
- For internal use only.
Products benefits
Installation
- Further improvement of the installation and removal in support thanks to the new generation of plastic hooks.
Usage
- The ideal solution to adapt the speed of ventilation
Advantages
- The ideal solution to adapt the speed of ventilation
- It is coordinated with the L.NOW aesthetic
Technical Characteristics
Mounting method
Flush-mounted
Colour
Gold
RAL-number
1019
Nominal current
10 A
Output voltage (Min-Max)
110-220 V
Number of phases
1
Power control stepless
Yes
Number of steps
1
Basic element without cover
No
Method of operation
Turn button
Lighting
None
Switching contact
No
With temperature sensor
No
Suitable for external humidity sensor
No
Reversible
No
With on/off switch
No
Suitable to control multiple fans
No
Shutter control option
No
Height
45 mm
Width
22 mm
Depth
61 mm
Degree of protection (IP)
IP20
