MatixGO BTicino

Connected socket module

Name: Connected socket module
Brand: BTicino
SKU: BT-JW4531C
Availability: InStock

BT-JW4531C | 8005543715352

Connected socket module - wiring to a power outlet, allows to remotely control appliances and check the consumption (instantaneous, daily, monthly).It is also possible to receive notifications in case of anomalous consumption. The connected socket module is compatible with any device electric and large appliances up to 16 A 3680 W max. (protected against overloads). It is equiped with a LED light lit in blue when it is on. This option can be enabled or disabled in the “Home+Control” app. It can be associated with “wireless light switches”. Power supply 110-230 Va.c. - 1 module - White

Compare

Description

The module for connected power outlet allows you to control your electrical appliances remotely via the Home + Control app or by using your voice, and to track your appliances’ consumption from your smartphone

Product characteristics

LED indicator with locator function which can be activated in the app
Compatible with any electrical appliance or large household appliance
Measures instantaneous and total electricity consumption
Color White
Packaging 100% plastic free: delivered with dedicated and new packaging in 100% paper, water-based painted and use of ecological glues.

Recommendations / Restrictions

To add a power outlet to your connected installation, you first need to purchase and install a MatixGO with Netatmo connected starter pack. To control your power outlet, you need to pair one or more MatixGO with Netatmo wireless switches with it.

Products benefits

Installation

The MatixGO with Netatmo power outlet module is easily installed in place of an existing standard power outlet and needs a standard-depth flush-mounting box.

Usage

Voice control of your lights and electrical appliances via a voice assistant

Advantages

Perfect aesthetic integration with the installed wiring devices

Technical Characteristics

Suitable for dimmer No

Suitable for pulse button No

Suitable for roller shutter switch No

Suitable for venetian shutter switch No

Suitable for venetian-/roller shutter switch No

Suitable for switch No

In housing Yes

In tube base housing No

Printed circuit board/module No

Current supply 230 V AC

Push button mode No

Switching mode Yes

With manual radio transmitter Yes

With radio coding device No

With radio controlled push button No

Number of relays 1

Mounting method Flush-mounted

Material Plastic

Material quality Thermoplastic

Halogen free Yes

Surface protection Untreated

Surface finishing Glossy

Type of fastening Mounting with screw

Colour White

RAL-number (similar) 9003

Transparent No

Suitable for degree of protection (IP) IP20

Degree of protection (NEMA) Other

Radio frequency 2400 MHz

Modulation FM

Rolling code system Yes

Number of commands 0

Compatible with Apple HomeKit Yes

Compatible with Google Assistant Yes

Compatible with Amazon Alexa Yes

IFTTT support available Yes

Width 22.5 mm

Height 45 mm

Depth 45.5 mm

Built-in depth 35.5 mm

degree of impact strength (IK) IK04

Operating / setting temperature (Min-Max) 5-45 °C

Storage temperature (Min-Max) 0-45 °C

Standby consumption 1.8 mA

Mandatory neutral Yes

Stress test conformity (1000V) No

Antimicrobial treatment No

Contains Batteries and/or Accumulator No

Connected object Yes

Operating method Zigbee

Application store for download App Store, Google Play Store

Programming way Smartphone apps

With voice command Yes

Programmable Yes

Interoperable connection Protocol Yes

Connectable by Internet box Yes

Compatible voice assistants Google Assistant, Amazon Alexa, Apple Siri

Application name Home + Control

Product use function Energy distribution

Documentation

Catalog Commercial Page

CAT_MTXGO | PDF (24.9 MB) | EN

Connected socket module
