  • Toroid for earth leakage relay item G701/2 diametre 150 mm - Idn=0.5A - In=1200A
Btdin BTicino

Toroid for earth leakage relay item G701/2 diametre 150 mm - Idn=0.5A - In=1200A

BT-G701T/150A | 8012199377889
Toroid for earth leakage relay item G701/2 diametre 150 mm - Idn=0.5A - In=1200A
Technical Characteristics
Model Single-phase current converter
Rated primary current 250 A
Rated secondary current 0.5 A
Overcurrent limiting factor FS 5
Calibrated Yes
With contact protection Yes
Height opening (Min-Max) 150-150 mm
Width opening (Min-Max) 150-150 mm
Opening diameter 150 mm
Snap mounting No
Secondary connection Screw connection
Number of primary inputs 1
Documentation
1 documents
Instruction Use
B6252B | PDF (146 KB)
