  6. BT-FL4654W
  • Temperature probe with backlit display, in plastic material (White color)
Smart Hotel BTicino

Temperature probe with backlit display, in plastic material (White color)

BT-FL4654W | 8005543625736
Temperature probe with backlit display, in plastic material (White color). It controls the temperature of an individual zone.It has a temperature and an input for the connection of a contact line (e.g. window contact).It can be used for the management of differenttypes of systems, and the adjustment of the fanspeed when Fan Coils are used.Possibility of automatic operation (summer/winter),with compatible systems.SCS-BUS connection - Sizes: 3 modules.
Description

The thermostat is the main product to control and modify temperature and manage fan speed. It embeds temperature and humidity sensor.

Product characteristics
  • Full touch plate surface
  • surface mounted installation or fully flush-mounted
  • Action on the product with visual feedback for the user
Recommendations / Restrictions
  • to be used within Legrand Guest room management system
Products benefits
Installation
  • Installation in standard back boxes with its own support frame. No dedicated box required
Usage
  • Improved user experience thanks to intuitive icons and feedback upon actions
Advantages
  • Action feedback for the user
  • Full flush mounted installation option
Technical Characteristics
Bus system KNX No
Bus system KNX-RF (Radio Frequency) No
Bus system radio frequency No
Bus system LON No
Bus system Powernet No
Other bus systems Other
Radio frequency bidirectional No
Mounting method Flush-mounted
With anti-theft/dismantling protection No
With bus connection Yes
Number of actuation points 0
Number of buttons 4
With LED indication Yes
With label area No
With display Yes
Material Plastic
Material quality Thermoplastic
Surface protection Untreated
Surface finishing Glossy
Colour White
RAL-number (similar) 9003
Transparent No
With room temperature controller Yes
With IR sensor No
Degree of protection (IP) IP20
Width 129 mm
Height 93 mm
Depth 42 mm
Built-in depth 30 mm
degree of impact strength (IK) IK02
Operating / setting temperature (Min-Max) 0-40 °C
Storage temperature (Min-Max) -20-70 °C
Frequency (Min-Max) 0-0 Hz
Standby consumption 8 mA
Terminal marking indication No
Halogen free Yes
Antimicrobial treatment No
Terminals capacity (Min-Max) 0-0 mm²
Cable nature for connection Flexible or rigid
Label space/information surface No
Addressable Yes
Connected object No
Operating method SCS
Programmable Yes
Documentation
1 documents
Instruction Use
LE10375AB | PDF (203 KB) | EN · FR · IT
1 documents
BIM Data
BIM_HOTEL_UX_TOUCH_THERMOSTAT | RFA (688 KB) | EN
