Smart Hotel BTicino

Key card reader + Outside the door indicator (White color) in plastic material.

BT-FL4651W | 8005543625705
Key card reader + Outside the door indicator (White color) in plastic material.It includes key card reader in RFID technology + DO NOT DISTURB (DND) and MAKE UP THEROOM (MUR) indicators and bell pushbutton.The device has a NC clean contact controlled by the bell symbol. The contact can be programmed for the bell function, or the electric door lock release.Vertical installationConnection to SCS-BUS, dimension: 3 modules.
Description

External indicator with badge reader which includes door bell and indicator for romm services like make-up room or do not disturb.

Product characteristics
  • Full touch plate surface
  • surface mounted installation or fully flush-mounted
  • Multi-color icons based on room status
  • Action on the product with visual feedback for the user
Recommendations / Restrictions
  • to be used within Legrand Guest room management system
Products benefits
Installation
  • Installation in standard back boxes with its own support frame. No dedicated box required
Usage
  • All icons are lit based on room status to provide clear indication to guest and staff
Advantages
  • Action feedback for the user
  • Full flush mounted installation option
  • Backlit icons with room status indication
Technical Characteristics
Bus system KNX No
Bus system KNX-RF (Radio Frequency) No
Bus system radio frequency No
Bus system LON No
Bus system Powernet No
Other bus systems Other
Radio frequency bidirectional No
Mounting method Flush-mounted
With anti-theft/dismantling protection No
With bus connection Yes
Number of actuation points 0
Number of buttons 2
With LED indication Yes
With label area No
With display Yes
Material Plastic
Material quality Thermoplastic
Surface protection Untreated
Surface finishing Glossy
Colour White
RAL-number (similar) 9003
Transparent No
With room temperature controller No
With IR sensor No
Degree of protection (IP) IP20
Width 129 mm
Height 93 mm
Depth 42 mm
Built-in depth 30 mm
degree of impact strength (IK) IK02
Operating / setting temperature (Min-Max) 0-40 °C
Storage temperature (Min-Max) -20-70 °C
Frequency (Min-Max) 0-0 Hz
Standby consumption 12 mA
Terminal marking indication No
Halogen free Yes
Antimicrobial treatment No
Terminals capacity (Min-Max) 0-6 mm²
Cable nature for connection Flexible or rigid
Label space/information surface No
Addressable Yes
Connected object No
Operating method SCS
Programmable Yes
