2-way switch with zero central 2NO - 32A - 230/400V - 2 modules

Name: 2-way switch with zero central 2NO - 32A - 230/400V - 2 modules
Brand: BTicino
SKU: BT-F62N32C
Availability: InStock

BT-F62N32C | 8005543556696

2-way switch with zero central 2NO - 32A - 230/400V - 2 modules DIN

Compare

Technical Characteristics

Switching function Two-way switch

Number of contacts as normally open contact 0

Number of contacts as normally closed contact 0

Number of contacts as change-over contact 2

Number of poles 4

Rated current 32 A

Rated voltage 400 V

Min. rated voltage 380 V

Short-circuit breaking capacity (Icw) 0.384 kA

Voltage type AC

With complemantary luminous signal No

Colour calotte Other

Lamp type Other

Lamp socket Other

Width in number of modular spacings 2

Built-in depth 44 mm

Degree of protection (IP) IP20

Width 35.6 mm

Height 94 mm

Depth 76 mm

Operating / setting temperature (Min-Max) -5-40 °C

Storage temperature (Min-Max) -10-70 °C

Terminal marking indication Yes

Connection type Screwed terminal

Terminals capacity (Min-Max) 1.5-6 mm²

Label space/information surface Yes

Mounting method DIN rail

Documentation

Technical Sheet

IDP000067EN_01 | PDF (122 KB) | EN
