Ringtone Vn= 8/12Vac - 4.8VA - 1 module

Name: Ringtone Vn= 8/12Vac - 4.8VA - 1 module
Brand: BTicino
SKU: BT-F36/12
Availability: InStock

BT-F36/12 | 8012199129938

Ringtone Vn= 8/12Vac - 4.8VA - 1 module DIN

Compare

Technical Characteristics

Housing colour Grey

Housing material Plastic

Nominal voltage (Min-Max) 12-12 V

Type of current AC

Built-in battery No

Electricity consumption (Min-Max) 0.42-0.42 A

Loudness 84 dB

Wireless No

Degree of protection (IP) IP20

Degree of protection (NEMA) Other

Width in number of modular spacings 1

degree of impact strength (IK) IK05

Operating / setting temperature (Min-Max) -10-60 °C

Storage temperature (Min-Max) -10-60 °C

Frequency (Min-Max) 50-60 Hz

Terminal marking indication Yes

RAL-number 7035

Halogen free No

Antimicrobial treatment No

Terminals capacity (Min-Max) 1.5-10 mm²

Cable nature for connection Flexible or rigid

Label space/information surface Yes

With complemantary luminous signal No

Contains Batteries and/or Accumulator No

Number of ringtones 1

Connected object No

With voice command No

Programmable No

Connectable by Internet box No
