Lowered section control for the managing of a single actuator or two actuators.
BT-AM5832/2
|
8012199838311
Description
Màtix - control for single or double loads– can drive a single actuator for single or double loads or two actuators for single loads or independent double loads. – to be completed with 1 2-module key cover or 2 1-module key covers.
Product characteristics
- Rated voltage 27Vdc
- Rated current 9mA
- N° of modules 2
Technical Characteristics
Bus system KNX
No
Bus system KNX-RF (Radio Frequency)
No
Bus system radio frequency
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequency bidirectional
No
Mounting method
Flush-mounted
With anti-theft/dismantling protection
No
With bus connection
Yes
Number of actuation points
2
Number of buttons
4
With LED indication
Yes
With label area
No
With display
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Colour
Other
Transparent
No
With room temperature controller
No
With IR sensor
No
Degree of protection (IP)
IP20
Min. depth of built-in installation box
55 mm
Width
45 mm
Height
45 mm
Depth
24 mm
degree of impact strength (IK)
Not applicable
Operating / setting temperature (Min-Max)
5-35 °C
Storage temperature (Min-Max)
-10-70 °C
Frequency (Min-Max)
0-0 Hz
Standby consumption
8.5 mA
Terminal marking indication
Yes
Halogen free
No
Antimicrobial treatment
No
Terminals capacity (Min-Max)
0.34-2.5 mm²
Cable nature for connection
Flexible or rigid
Label space/information surface
No
Addressable
Yes
Contains Batteries and/or Accumulator
No
Connected object
No
Programmable
Yes
Interoperable connection Protocol
Yes
Connectable by Internet box
No
Product use function
Lighting management
Documentation
1 documents
Technical Sheet
MQ00286-D-EN | PDF (187 KB) | EN
1 documents
PEP-EPD
LGRP-01140-V01.01-EN | PDF (750 KB) | EN
1 documents
B2B Documents
CAT-MTX | PDF (14.8 MB) | EN
