Matix BTicino

Removable and rechargeable torch

BT-A5780N | 8005543540060
Removable and rechargeable torch with automatic ignition device. It turns on automatically in case of power failure - push & pull the extraction system (press and pull) complete with recharging base - white Light LEDs with high luminous efficiency - ON / OFF switch and SPOT button to increase the brightness when needed - interchangeable batteries Ni-MH battery without memory effect - Autonomy of 2 hours - low consumption in stand-by 0.4W - Power 230 VAC - 2 modules
Technical Characteristics
Mounting method Built-in
Suitable for labelling type Sticker
Suitable for continuous circuit Yes
With remote switch connection No
Emergency function monitoring system None
Emergency power supply system Peripheral (individual battery)
Battery technology NiMH
Lamp type LED not exchangeable
With light source Yes
Lamp holder Other
Housing material Plastic
Housing colour White
Material cover Plastic, opal
Voltage type AC
Nominal voltage (Min-Max) 110-240 V
Nominal current (Min-Max) 450-450 mA
Degree of protection (IP) Other
Rated luminous flux according to IEC 62722-2- 1 (Min-Max) 0-0 lm
Nominal operation time (Min-Max) 2-2 h
Width 44 mm
Height/depth 43 mm
Length 47 mm
Built-in width 44 mm
Built-in height/depth 39 mm
Built-in length 47 mm
Contains Batteries and/or Accumulator Yes
Battery ou Accumulator (Pack1) Accumulator (rechargeable)
Element Composition (Pack1) Nickel metal hydride
Number of Pack 1 1
Number of Single Element (Pack1) 2
Single Element weight (Pack1) 0 g
Regulation Type (Pack1) P : Portable (Standard format)
Connected object No
Documentation
1 documents
Instruction Use
LE07570AA | PDF (476 KB)
