Lamp carrier opalescent - 24V
BT-5060/1
|
8012199027487
Technical Characteristics
Assembly arrangement
Basic element with central cover plate
Lamp holder
Other
With light source
Yes
With flashlight
No
With fixed symbol/imprint
Yes
With exchangeable symbol
No
Application as button
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9016
Transparent
Yes
Colour light source
White
Suitable for degree of protection (IP)
IP20
Nominal voltage
24 V
Max. lamp power
3 W
Device width
23 mm
Device height
41 mm
Device depth
35 mm
degree of impact strength (IK)
IK06
Operating / setting temperature (Min-Max)
-5-50 °C
Storage temperature (Min-Max)
-10-70 °C
Connection type
Screwed terminal
Cable section (Min-Max)
2.5-2.5 mm²
