Linea 5000 with Netatmo entrance panels and their add-on modules can be installed flush mounted or surface/wall mounted in different combinations.
Flush-mounted installation of the display module 345000
The finishing frame, is available in 5 different finishes: Aluminium (345101), Nickel (345102), Gold (345103), Titanium (345104) and Steel (345105).
Wall-mounted installation of the display module 345000
Wall mounted box available in Aluminium finish (345331) or Nickel finish (345332). The finishing frame, is available in 5 different finishes: Aluminium (345101), Nickel (345102), Gold (345103), Titanium (345104) and Steel (345105).
Stand alone flush-mounted installation of the accessory modules
Accessory module can be keyboard (345500-345510) or RFID Smart access (345520). The finishing frame, is available in 5 different finishes: Aluminium (345201), Nickel (345202), Gold (345203), Titanium (345204) and Steel (345205).
Stand alone wall-mounted installation of the accessory modules
Wall mounted box available in Aluminium finish (345311) or Nickel finish (345312). Accessory module can be keyboard (345500-345510) or RFID Smart access (345520). The finishing frame, is available in 5 different finishes: Aluminium (345201), Nickel (345202), Gold (345203), Titanium (345204) and Steel (345205).
Flush-mounted installation (3+1) display module 345000 + additional module
Additional module can be keyboard (345500-345510) or inductive loop (345530). To be completed with the proper finishing frames, available in 5 different finishes.
Wall-mounted installation (3+1) display module 345000 + additional module
Wall-mounted box available in Aluminium finish (345341) or Nickel finish (345342). Additional module can be keyboard (345500-345510) or inductive loop (345530). To be completed with the proper finishing frames, available in 5 different finishes.
Installation recommendations
It is recommended that the entrance panels are installed at a height of 180 cm (high level) from the floor. To allow the use of the entrance panels by disabled individuals, the recommended installation height is 90 - 130 cm (high level) – Recommended height, unless different regulations are specified.
The camera must not be installed in front of light sources or in positions where the subject being filmed is backlit.
Dimensional data
2 wires door entry system technical guide
Prepare and design your system with the technical guide. An indispensable tool for the professional with all the updated technical information useful for designing, sizing, connecting, configuring and maintaining 2 wires audio and video door entry systems.
